VBAN Audio Protocol for any network infra structure



VBAN Network Example with Voicemeeter Audio HUB & Receptors

VBAN, The VB-Audio Network Protocol,

VBAN Protocol has been designed for real-time transport of digital audio stream in IP-based network environments. VBAN allows to send or / and receive audio to / from other computers of any local networks. Voicemeeter already allows easy way to manage several incoming / outgoing streams.
For Any Local Network Infra-Structure

Based on UDP Protocol, VBAN is made for Audio Pro and Audiophiles, to transport multichannel audio in native PCM format (all sampling rate supported). Developed like a "RADIO" transmitter / receptor system, the sender is always master and the receiver is always slave.








Voicemeeter VBAN Implementation
The easiest way to send or receive several VBAN Audio Streams



VBAN Implementation in Voicemeeter Banana
Voicemeeter Audio HUB,

Voicemeeter now offers VBAN features to send up to 4 audio streams and receive up to 2 ones on its virtual input(s). Just define a destination IP-Address to send Audio to another computer of a local network... Use 255 UDP Broadcast Address to send Audio Stream to all computers of a local network.
Easy Way to Manage VBAN

VBAN Stack in Voicemeeter is able to manage any audio stream, in any audio format (PCM 16 / 24bits), in any sample rate (independently from the mainstream sample rate), from 1 to 8 channels. So it's possible to send/receive stereo, 5.1 or even 7.1 signal in native PCM format (HD Audio).








VBAN Receptor
The Simple Application To listen VBAN Audio Streams



VBAN Receptor

INSTALL VBAN Receptor.

VBAN-Receptor is a simple Application to receive and listen VBAN Audio Streams.

All formats / samplerates supported (1 to 8 channels).

VBAN-Receptor 1.0.0.3 (ZIP Package)
Standalone Application (XP, VISTA, WIN7, WIN8, WIN10 32/64 bits)

  VBANReceptor_v1003.zip (2.00 MB - FEB 2017)
  Click Here to download from alternative web site.

INSTALLATION: none - copy it on hard disk/desktop and/or Run it


VBAN Receptor for Mobile Devices.


  VBAN-Receptor for iOS
  iPhone, iPad or iPod-Touch (iOS 7.0 or later).


  VBAN-Receptor for Android
  phone, tablet (Android 4.2 or later).
Purchase License / Support Us !

VBAN-Receptor, as Voicemeeter accessories, is also distributed as Donationware! It means you can set the License price as you want!

For VBAN-Receptor Application, recommended License Price is around 5 to 10 Euro, but all other participations are Welcome. Thanks to all!

You also might install and test it first, and make a donation if you find it useful. (for donation above 100 Euro, or for volume licensing / special deals, you can contact us to get quotation / invoice).





In the Spotlight:
Take a look on the last Video to about VBAN-Streaming capabilities and functions.


Thanks to all to talk about our applications, feel free to contact us to let us know about your last video, review, use case...



SPECIFICATIONS
Application Type:
VBAN Receptor (VBAN End Point)
Compatibility:
Windows XP, VISTA, WIN7, WIN8, WIN8.1, WIN10 (32 / 64 bits)
PC Configuration:
Min: Celeron / Duo Core 1.8 GHz - 512 MB RAM - Disk < 100 MB

Number of Audio Device I/O:


1 Physical Output

BUS / Layer:
1x BUS / Single Layer
Audio Engine Capabilities:

32, 44.1, 48, 88.2 or 96 kHz
Output A1 (Main):
WDM, KS, MME, ASIO (32 kHz to 96 kHz) - 1 to 8 channels

VBAN Stream

Single Stream (all samplerates - 1 to 8 channels).

Strip Processing:
- 3 Bands Graphic Equalizer.
- Mute.
BUS Processing:
- Integrated Limiter and Peak Remover.
- Mix Down to convert 5.1 or 7.1 to Stereo.
- Stereo Repeat (Stereo signal copied on channel 3,4 / 5,6 / 7,8)
- Mono
Others:
- Output Delay in system settings dialog box.








VBAN-Spot
To Broadcast VBAN Stream on WIFI Access Point(s)



VBAN Spot Application

INSTALL VBAN Spot.

VBAN-Spot is a simple application to broadcast a VBAN Audio Streams over your local network! VBAN-Spot get audio from any recording devices to send it as VBAN Stream to any VBAN Receptor devices.

Especially made for VBAN-Receptor lite version, With VBAN Spot, it is now possible to use a WIFI AP as radio antenna and broadcast audio conference, show, multi lang, music, movie sound to your audience, up to 250 mobile devices!
Just Run VBAN-Spot Setup Program to install the application on your system.

VBAN-Spot 1.0.0.1 (ZIP Package)
Standalone Application (XP, VISTA, WIN7, WIN8, WIN10 32/64 bits)

  VBANSpotSetup_v1001.zip (2.83 MB - APR 2017)
  Click Here to download from alternative web site.

INSTALLATION: Just Run setup program.

Purchase License / Support Us !

To make VBAN-Spot affordable for everyone, it is distributed as Donationware! It means you can use it and pay the license price you want, when you want, according to your means or usage !

For VBAN-Spot Application, price range is around 5 to 100 Euro / Dollar. A registration code is given to activate your license. The Challenge Code is given by your application running on your computer (see Menu > About Box).

Purchase VBAN-Spot License

Purchase VBAN-Spot License

VBAN Spot Workflow


Send Audio To Mobile Device with VBAN Receptor Lite
How to send audio to your Mobile Devices ? Learn More...

  VBAN-Receptor Lite for iOS (Free)
  iPhone, iPad or iPod-Touch (iOS 7.0 or later).


  VBAN-Receptor Lite for Android (Free)
  phone, tablet (Android 4.2 or later).


SPECIFICATIONS
Application Type:
VBAN Transmitter (VBAN-Spot)
Compatibility:
Windows XP, VISTA, WIN7, WIN8, WIN8.1, WIN10 (32 / 64 bits)
PC Configuration:
Min: Celeron / Duo Core 1.8 GHz - 512 MB RAM - Disk < 100 MB

Number of Audio Device I/O:


1 Physical Input (WDM, KS, MME, ASIO)

Audio Sources:
Audio device or VBAN Stream
Audio Engine Capabilities:

44.1, 48, 88.2 or 96 kHz
Output (Monitoring):
WDM, KS, MME, ASIO (32 kHz to 192 kHz) - 1 to 8 channels

VBAN Stream

Single Stream (44100 Hz, 16bits Stereo).

Network:
up to 255 address in any 255 address range.
Detection:
Detection by standard PING
Others:








VBAN PROTOCOL
The easiest way to transport audio stream on local network.



VBAN Packet Structure

VBAN PROTOCOL specifications

VBAN Protocol official specifications by V.Burel:
Download VBAN Protocol Document

To Talk about VBAN protocol and applications:
VBAN Protocol Forum

VBAN PROTOCOL Open Source Project

VBAN Protocol is made simple to be integrated easily and quickly by any application developers or hardware manufacturers. As example of implementation, a VBAN-Receptor is available as open source project for Linux Operating System on Benoit Quiniou GitHub
